Description
Haier HBU-48E/DC 4 Ton DC Inverter Ceiling Cassette AC
The Haier HBU-48E/DC 4 Ton DC Inverter Ceiling Cassette AC is designed for large commercial and professional spaces that require high cooling capacity, wide air distribution and a ceiling-mounted installation. Haier officially categorizes this model as a 4 Ton DC Inverter Heat & Cool cassette AC, making it suitable for offices, showrooms, restaurants, conference rooms and other large indoor areas.
4 Ton DC Inverter Performance
The HBU-48E/DC provides powerful inverter climate control with a rated 14.1 kW cooling capacity and 14 kW heating capacity.
Its DC inverter system adjusts compressor operation according to cooling or heating demand rather than relying only on fixed-speed on/off cycles, helping maintain more controlled indoor temperatures during extended use.
14.1 kW Cooling Capacity
Haier officially specifies 14.1 kW cooling capacity, equivalent to approximately 48,000 BTU/h.
This high output places the HBU-48E/DC in the 4 Ton category and makes it suitable for large commercial spaces where smaller residential AC capacities may not be sufficient.
Heat & Cool Operation
The Haier HBU-48E/DC supports both cooling and heating, allowing year-round operation.
Official capacities include:
- Cooling Capacity: 14.1 kW
- Heating Capacity: 14 kW
This makes it useful for commercial areas that require climate control in both summer and winter.
Round-Way Air Flow
Haier highlights Round Way Air Flow for this cassette model.
The ceiling-mounted cassette design distributes conditioned air in multiple directions from a central position, helping achieve broader coverage across large or open-plan spaces compared with conventional wall-mounted airflow.
2,050 m³/h High Airflow
Haier specifies an airflow volume of 2,050 m³/h on high setting.
This strong airflow supports faster and more even distribution of conditioned air throughout larger rooms, offices, showrooms and other high-occupancy spaces.
T3 High-Ambient Design
The HBU-48E/DC features High Ambient Design (T3).
Haier’s commercial cassette information states that its T3 outdoor system is designed to continue cooling operation when outside temperatures reach up to 52°C, making this feature particularly relevant for demanding Pakistani summer conditions.
Three-Phase Power Supply
Unlike typical domestic split ACs, the HBU-48E/DC requires a 3 Phase, 380V, 50Hz power supply.
This is an important installation requirement and should be confirmed at the site before purchase.
Cooling & Heating Power Input
Haier officially specifies:
- Cooling Rated Power Input: 4.4 kW
- Heating Rated Power Input: 4.3 kW
Actual electricity consumption will vary according to operating load, temperature setting, insulation, occupancy, ambient conditions and installation quality.
R410A Refrigerant
The HBU-48E/DC uses R410A refrigerant.
Haier specifies the following refrigerant pipe sizes:
- Liquid Pipe: 9.52 mm
- Gas Pipe: 19.05 mm
These specifications should be considered during professional installation and piping planning.
Ceiling Cassette Installation
A ceiling cassette AC is particularly useful where users want strong climate control without occupying wall or floor space.
Typical applications include:
- Corporate offices
- Large meeting rooms
- Retail showrooms
- Restaurants
- Commercial halls
- Clinics and waiting areas
- Open-plan workspaces
The installation requires suitable ceiling space and should be carried out by a qualified professional.
Built-In Drain Pump
Haier’s 4-way cassette platform includes a built-in high-head drain pump, which helps remove condensate water and gives installers additional flexibility when routing drainage within a ceiling installation.
Long Pipe Length
Haier lists Long Pipe Length among the official features of the HBU-48E/DC.
This can provide greater installation flexibility when the indoor and outdoor units cannot be positioned close together, subject to Haier’s installation limits and professional setup requirements.
Specifications
| Specification | Details |
|---|---|
| Brand | Haier |
| Model | HBU-48E/DC |
| Product Type | Ceiling Cassette AC |
| Capacity | 4 Ton |
| Category | DC Inverter Heat & Cool |
| Cooling Capacity | 14.1 kW / Approx. 48,000 BTU/h |
| Heating Capacity | 14 kW |
| Cooling Rated Power Input | 4.4 kW |
| Heating Rated Power Input | 4.3 kW |
| Power Supply | 3 Phase / 380V / 50Hz |
| Air Flow | 2,050 m³/h |
| Air Distribution | Round Way Air Flow |
| High Ambient Design | T3 |
| High-Ambient Operation | Up to 52°C |
| Refrigerant | R410A |
| Liquid Refrigerant Pipe | 9.52 mm |
| Gas Refrigerant Pipe | 19.05 mm |
| Indoor Unit Dimensions | 840 × 840 × 290 mm |
| Energy Rating | 3 Star |
| Drain Pump | Built-In |
| Installation Type | Ceiling Cassette |
| Operation | Cooling & Heating |
